Sanden Compressor For Ford/Sterling SANDEN #: 4305 OEM: XC4H-19D629AA

Description Sanden Compressor For Ford/Sterling SANDEN #: 4305 Replaces OEM: XC4H-19D629AA Make: Sanden Manufacturer: Sanden Manufacturer #: 4305 Application: Ford/Sterling Trucks Description: Sanden STD Comp 8 gr 119mm Volts: 12V Other OE Sanden #: 4305 Additional OE Sanden #: 4427 Clutch Diameter: 119mm No. of Grooves: 8 groove Belt Type: Serpentine No. Comp. Cylinders: 7 cyl Comp. Displacement (ci): 9.5 cu.in. Factory Oil Charge: 300cc Oil Fitting Port Position: Top Fitting Style: Ford O-ring Pad Head Type: WJ Wire Type: 2 Wire Ford F5TB-14A464-FA W/ Wedge Replacement Clutch Assy.: 5122 Replacement Head Assy: NSS Model: SD7H15HD Oil Type: PAG100 Product Name: A/C Compressor w/clutch Refrigerant Type: R134a Rotation: CW O-Ring #1: 0013 O-Ring #2: 0015 Shaft Type: Long Key Shaft Diode Protection: None DO NOT POWER PROBE THE COMPRESSOR CLUTCH YOU WILL BLOW OUT THE DIODE AND THEN THE CLUTCH WON’T WORK AND THE WARRANTY WILL BE VOID A/C COMPRESSOR
